Stepper motors

You will find below our range of stepper motor, from permanent synchronous stepper motor and hybrid size 17 (42 mm square), 23 (57 mm square) and 34 (86 mm square).

Our latest range of Hybrid stepper motors, the 6600, uses Neodymium-Iron boron magnets which give them an excellent level of performance.

From these came the motors with integrated electronics from the 8656 (size 17) and 8660 (size 23) range.

Mechanical or electronic modifications are possible on our standard motors, do not hesitate to submit your adaptations to us.

Likewise, since these motors can receive a rear axle, mounting of an encoder or brake is possible on request.

Stepper motors

Synchronous motors:

This product range is quite old, some references have become obsolete. Contact us to know the availability of products.

Integrated electronic motors:

This new range of hybrid motor with integrated electronics, is characterized by its reduced size and by a very low vibration level (and therefore a very reduced sound level), mainly due to the standardization on our range of electrical damping of µpas.

LOADSENSE:

functions:

- Intelligent closed loop driver with torque control and detection

- Low noise control

- Slight increase in temperature due to permanent current regulation

- High yield

- High torque at low speed

- Adaptable to all standard Sonceboz Nema 17-23 engines: 6540,6600 and 8660 series

- Wide choice of communications possible, such as CAN, PWM, clock & direction, RS485, I2C interfaces

Benefits:

- Enables monitoring of engine operation and preventive maintenance

- Analysis of the motor control loop

- Lossless step guarantee

- Without gearbox: compact size for easier mounting

- Reduced power consumption

- An all-in-one solution for servo

- Reliable and precise

- The intelligent electronic system continuously adapts the current in the phases to respond to the decoupling load.

8656-13 New low noise 8656 18 - std 8656-18 low noise 8660 13 - std 8660 15 - cool 8660 15 - low noise 8660 15 - std new 8660 20 - std new 8660 20 - cool 8660 30 C - cool 8660 30 C - new 8660 load sense 8663 load sense

6600 and 6500 range:

This range of high performance hybrid motor is characterized by a rotor using a rare earth magnet and a stator supporting large currents. These engines are therefore among the most efficient on the market. The relatively old 6500 hybrid engine range is gradually being replaced by the 6600 "Top Drive" range. These are identical in mechanical and electrical terms, but more efficient due to the improvement in the rotor.

NEMA 17 6540 13 NEMA 17 6540 18 NEMA 23 6600 15 NEMA 23 6600 20 NEMA 23 6600 30 NEMA 34 6630 24 NEMA 34 6630 37 NEMA 34 6630 50

Permanent magnet stepper motor:

6231S 6231A

LINEAR ACTUATORS

Standard linear actuators:

7211 7214 7217 7220 7230 8210 8310

Hydraulic linear actuator:

This reversible actuator, 8366 range, has been developed for an on-board agricultural application, in order to replace the traditional proportional pilot valve which controls in position the hydraulic distributor valve (250 bars) of the tractor.

BLDC Motors

5642r017 5846 5642

REDUCERS

All of our production of stepper and brushless motors being in standard NEMA format, we can offer you a wide range of reducers. We can assemble within a very short time, planetary reducers adapted to our engines with different reduction ratios.

Depending on your needs, we will offer you the range of gearbox adapted to your lifespan and the desired precision.

Do not hesitate to submit your needs.

ENCODERS AND BRAKES

All of our production of stepper and brushless motors are available with a rear axle, which allows us to offer you the assembly of encoders or standard brakes, adapted to your needs.

Do not hesitate to contact us according to your needs.

STEERING ELECTRONICS

We are able to offer you control electronics for all of our motors. You will find below standard Power Drivers, "intelligent" Drivers allowing to record cycles, or with limit switch inputs, or encoder, etc. and these in Sinus control.

We remain at your disposal to study your steering need, from the unitary part to the OEM project

Step by step driver:

9103
